Mã sản phẩm: ds2422+
Processor: Intel Core i3 (Dual Core 3.4 GHz)
Memory: 1 x 4 GB DDR3 ECC
External Ports: USB 2.0 Port 2, USB 3.0 Port 2
Expansion Port: 2
Hard Drive: Support 3.5" SATA(III) / SATA(II) HDD 2.5" SATA(III) / SATA(II) HDD 2.5" SATA(III) / SATA(II) SSD
CPU |
CPU Model | AMD Ryzen V1500B |
---|---|---|
CPU Quantity | 1 | |
CPU Architecture | 64-bit | |
CPU Frequency | 4-core 2.2 GHz | |
Hardware Encryption Engine (AES-NI) | ||
Memory |
System Memory | 4 GB DDR4 ECC SODIMM |
Memory Module Pre-installed | 4 GB (4 GB x 1) | |
Total Memory Slots | 2 | |
Maximum Memory Capacity | 32 GB (16 GB x 2) | |
Notes |
|
|
Storage |
Drive Bays | 12 |
Maximum Drive Bays with Expansion Unit | 24 (DX1222 x 1) | |
Compatible Drive Type* (See all supported drives) |
|
|
Hot Swappable Drive* | ||
Notes |
|
|
External Ports |
RJ-45 1GbE LAN Port* | 4 (with Link Aggregation / Failover support) |
USB 3.2 Gen 1 Port* | 2 | |
Expansion Port | 1 | |
Notes |
|
|
PCIe |
PCIe Expansion | 1 x Gen3 x8 slot (x4 link) |
File System |
Internal Drives |
|
External Drives |
|
|
Notes | exFAT Access can be installed for free from Package Center in DSM 7.0. In DSM 6.2 or earlier versions, exFAT Access needs to be purchased in Package Center. | |
Appearance |
Size (Height x Width x Depth) | 270 mm x 300 mm x 340 mm |
Weight | 9.5 kg | |
Others |
System Fan | 120 mm x 120 mm x 2 pcs |
Fan Speed Mode |
|
|
Easy Replacement System Fan | ||
Power Recovery | ||
Noise Level* | 25 dB(A) | |
Scheduled Power On / Off | ||
Wake on LAN / WAN | ||
Power Supply Unit / Adapter | 550 W | |
AC Input Power Voltage | 100V to 240V AC | |
Power Frequency | 50/60 Hz, Single Phase | |
Power Consumption | 73.11 W (Access) 32.12 W (HDD Hibernation) |
|
British Thermal Unit | 249.63 BTU/hr (Access) 109.67 BTU/hr (HDD Hibernation) |
|
Notes |
|
|
Temperature |
Operating Temperature | 0°C to 40°C (32°F to 104°F) |
Storage Temperature | -20°C to 60°C (-5°F to 140°F) | |
Relative Humidity | 5% to 95% RH | |
Certification |
|
|
Warranty |
Bảo hành phần cứng 3 năm, có thể mở rộng đến 5 năm với EW202 | |
Notes |
|
|
Environment |
RoHS Compliant | |
Packaging Content |
|
|
Optional Accessories |
|
|
Notes | All memory modules will operate at the maximum frequency specified by the CPU manufacturer. |
