SYNOLOGY DS220J

CPU	CPU Model	Realtek RTD1296
	CPU Quantity	1
	CPU Architecture	64-bit
	CPU Frequency	4-core 1.4 GHz
	Hardware Encryption Engine
Memory	System Memory	512 MB DDR4 non-ECC
	Notes	Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.
Storage	Drive Bays	2
	Compatible Drive Type* (See all supported drives)	3.5" SATA HDD 2.5" SATA HDD (with optional 2.5" Disk Holder) 2.5" SATA SSD (with optional 2.5" Disk Holder)
	Hot Swappable Drive*	-
	Notes	"Compatible drive type" indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.
External Ports	RJ-45 1GbE LAN Port	1
	USB 3.2 Gen 1 Port*	2
	Notes	The USB 3.0 standard was renamed to USB 3.2 Gen 1 by the USB Implementers Forum (USB-IF) in 2019.
File System	Internal Drives	EXT4
	External Drives	EXT4 EXT3 FAT NTFS HFS+ exFAT
	Notes	exFAT Access can be installed for free from Package Center in DSM 7.0. In DSM 6.2 or earlier versions, exFAT Access needs to be purchased in Package Center.
Appearance	Size (Height x Width x Depth)	165 mm x 100 mm x 225.5 mm
	Weight	0.88 kg
Others	System Fan	92 mm x 92 mm x 1 pcs
	Fan Speed Mode	Full-Speed Mode Cool Mode Quiet Mode Low-power Mode
	Brightness Adjustable Front LED Indicators
	Power Recovery
	Noise Level*	18.2 dB(A)
	Scheduled Power On / Off
	Wake on LAN / WAN
	Power Supply Unit / Adapter	60 W
	AC Input Power Voltage	100V to 240V AC
	Power Frequency	50/60 Hz, Single Phase
	Power Consumption	12.46 W (Access) 5.06 W (HDD Hibernation)
	British Thermal Unit	45.52 BTU/hr (Access) 17.27 BTU/hr (HDD Hibernation)
	Notes	Power consumption is measured when it is fully loaded with Western Digital 1TB WD10EFRX hard drive(s). Noise Level Testing Environment: Fully loaded with Seagate 2TB ST2000VN000 hard drive(s) in the idle state. Two G.R.A.S. Type 40AE microphones, each set up 1 meter away from the Synology NAS at the front and rear. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%
Temperature	Operating Temperature	0°C to 40°C (32°F to 104°F)
	Storage Temperature	-20°C to 60°C (-5°F to 140°F)
	Relative Humidity	5% to 95% RH
Certification	EAC CCC KC FCC CE BSMI VCCI RCM
Warranty	Bảo hành phần cứng 2 năm, có thể mở rộng đến 4 năm với Gói bảo hành mở rộng Plus
	Notes	Gói bảo hành chỉ áp dụng ở một số khu vực. Trước khi mua, vui lòng truy cập trang web chính thức của EW201/202 và Gói bảo hành mở rộng Plus để biết danh sách các khu vực đủ điều kiện. The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more)
Environment	RoHS Compliant
Packaging Content	Main Unit X 1 Accessory Pack X 1 AC Power Adapter X 1 AC Power Cord X 1 RJ-45 LAN Cable X 1 Quick Installation Guide X 1
Optional Accessories	VisualStation: VS360HD Surveillance Device License Pack Disk Holder: Type C

CPU

CPU Model

Realtek RTD1296

CPU Quantity

CPU Architecture

64-bit

CPU Frequency

4-core 1.4 GHz

Hardware Encryption Engine

Memory

System Memory

512 MB DDR4 non-ECC

Notes

Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.

Storage

Drive Bays

Compatible Drive Type* (See all supported drives)

3.5" SATA HDD
2.5" SATA HDD (with optional 2.5" Disk Holder)
2.5" SATA SSD (with optional 2.5" Disk Holder)

Hot Swappable Drive*

Notes

"Compatible drive type" indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.

External Ports

RJ-45 1GbE LAN Port

USB 3.2 Gen 1 Port*

Notes

The USB 3.0 standard was renamed to USB 3.2 Gen 1 by the USB Implementers Forum (USB-IF) in 2019.

File System

Internal Drives

EXT4

External Drives

EXT4
EXT3
FAT
NTFS
HFS+
exFAT

Notes

exFAT Access can be installed for free from Package Center in DSM 7.0. In DSM 6.2 or earlier versions, exFAT Access needs to be purchased in Package Center.

Appearance

Size (Height x Width x Depth)

165 mm x 100 mm x 225.5 mm

Weight

0.88 kg

Others

System Fan

92 mm x 92 mm x 1 pcs

Fan Speed Mode

Full-Speed Mode
Cool Mode
Quiet Mode
Low-power Mode

Brightness Adjustable Front LED Indicators

Power Recovery

Noise Level*

18.2 dB(A)

Scheduled Power On / Off

Wake on LAN / WAN

Power Supply Unit / Adapter

60 W

AC Input Power Voltage

100V to 240V AC

Power Frequency

50/60 Hz, Single Phase

Power Consumption

12.46 W (Access)
5.06 W (HDD Hibernation)

British Thermal Unit

45.52 BTU/hr (Access)
17.27 BTU/hr (HDD Hibernation)

Notes

Power consumption is measured when it is fully loaded with Western Digital 1TB WD10EFRX hard drive(s).
Noise Level Testing Environment: Fully loaded with Seagate 2TB ST2000VN000 hard drive(s) in the idle state. Two G.R.A.S. Type 40AE microphones, each set up 1 meter away from the Synology NAS at the front and rear. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%

Temperature

Operating Temperature

0°C to 40°C (32°F to 104°F)

Storage Temperature

-20°C to 60°C (-5°F to 140°F)

Relative Humidity

5% to 95% RH

Certification

EAC
CCC
KC
FCC
CE
BSMI
VCCI
RCM

Warranty

Bảo hành phần cứng 2 năm, có thể mở rộng đến 4 năm với Gói bảo hành mở rộng Plus

Notes

Gói bảo hành chỉ áp dụng ở một số khu vực. Trước khi mua, vui lòng truy cập trang web chính thức của EW201/202 và Gói bảo hành mở rộng Plus để biết danh sách các khu vực đủ điều kiện.
The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more)

Environment

RoHS Compliant

Packaging Content

Main Unit X 1
Accessory Pack X 1
AC Power Adapter X 1
AC Power Cord X 1
RJ-45 LAN Cable X 1
Quick Installation Guide X 1

Optional Accessories

VisualStation: VS360HD
Surveillance Device License Pack
Disk Holder: Type C
