CPU

4 4th Generation Inte®Xeon® Sapphire Rapids SP series

60 Cores for each Processor with 350W power consumption

Chipset

Intel®C741

Memory

64 DDR5 RDIMM Slots, 4800 MT/s Data Rate

Raid Controller

Onboard SATA Raid Controller

Standard PCIe HBA Controller or Raid Controller*

FBWC

8 GB Cache, support Supercapacitor protection*

Storage

50 SAS/SATA HDD/SSD Drives

32 U.2 NVMe Drives

Supports PCIe NVMe storage accelerator card,Dual hot-swappable SATA M.2 Kit

Network

1 Onboard 1Gbps Management Network Port

Onboard OCP 3.0 Slots for 4 GE or 2 10GE or 2 25GE NICs

PCIe Standard Slots for 1/10/25/40/100/200Gb Ethernet Adapter or 100/200Gb InfiniBand card

Expansion Slots

Up to 10 PCIe 5.0 x 16 Standard Slots

Up to 22 PCIe 5.0 x 8 Standard Slots

Up to 3 Onboard OCP 3.0 Slots

Ports

Standard:2 VGA Rear Port (1 Front, 1 Rear), 4 USB 3.0 Ports (2 Front, 2 Rear), 1 Management Port

Optional: Mounting Bracket Kit with Type-C port, Power-Button, UID

GPU

Supports dual and Single-Slot GPU Modules

Optical Drive

External Optical Disk Drive, Optional

Management

HDM Management System (with dedicated management port)

H3C iFIST/FIST, LCD touchable model

Security

Intelligent Front Security Bezel*

Chassis Intrusion Detection

TPM2.0

Silicon Root of Trust

2FA for HDM

Secure Decommissioning

Power supply

4 CRPS supplies, 2000W (N+N redundancy)

Titanium 850/1600W

Hot swappable N+1 Redundant Fans

Standards

CE，UL , FCC，VCCI，CB, etc.

Operating temperature

5°C to 45°C (41°F to 113°F) *

Dimensions

(H×W×D)

4U Height

Without a security bezel: 174.8x447x830mm (6.88x17.60x32.68 in)

With a security bezel: 174.8x447x858mm (6.88x17.60x33.78 in)
